How to make TeXForm use TemplateBox to generate code?

Question

If I define the TraditionalForm formatting of myFunction without TemplateBox, then TeXForm works properly:

ClearAll[myFunction]
myFunction /: HoldPattern[MakeBoxes[myFunction[a_, b_, c_], TraditionalForm]] :=
  SubsuperscriptBox[ToBoxes[a], ToBoxes[b], ToBoxes[c]]


myFunction[h, 1, 2] // TeXForm
(* h_1^2 *)

But if I try to define it using TemplateBox,

ClearAll[myFunction]
myFunction /: HoldPattern[MakeBoxes[myFunction[a_, b_, c_], TraditionalForm]] :=
  TemplateBox[
    {ToBoxes[a], ToBoxes[b], ToBoxes[c]}, "myFunctionTag",
    DisplayFunction :> (SubsuperscriptBox[#1, #2, #3] &)
  ];

TraditionalForm works correctly,

myFunction[h, 1, 2] // TraditionalForm

(* $h_1^2$ *)

but TeXForm does not return code to format the expression as in TraditionalForm:

myFunction[h, 1, 2] // TeXForm
(* \text{myFunctionTag}[h,1,2] *)

Instead, it is just replacing the head of the function with the tag of TemplateBox. What is the correct way to make TeXForm generate code out of a TemplateBox? I'm looking for a solution that can be programmed into a package.

Try using Rule instead of RuleDelayed in your TemplateBox definition. — Carl Woll, Jul 30 '17 at 21:46
The docs indicate that RuleDelayed is acceptable in a TemplateBox, so I don't think it's a bad question — Carl Woll, Jul 30 '17 at 22:34
@CarlWoll Please write an answer to this question, so I can accept. — QuantumDot, Jul 31 '17 at 18:28
Not relevant to the question, but note that using ToBoxes instead of MakeBoxes, on RHS, introduces evaluation leaks. — jkuczm, Aug 01 '17 at 10:00

score 6 · Accepted Answer · answered Jul 31 '17 at 20:51

The internal function used by TeXForm to process boxes is System`Convert`CommonDump`ExpandTemplateBoxes. This function is expecting the DisplayFunction option of a TemplateBox to use Rule, not RuleDelayed. Compare:

System`Convert`CommonDump`ExpandTemplateBoxes @ TemplateBox[
    {"a"},
    "FOO",
    DisplayFunction :> (#&)
]

System`Convert`CommonDump`ExpandTemplateBoxes @ TemplateBox[
    {"a"},
    "FOO",
    DisplayFunction -> (#&)
]

RowBox[{"FOO", "[", RowBox[{"a"}], "]"}]

"a"

When RuleDelayed is used, the box structure generated by the DisplayFunction is ignored. So, modify your TemplateBox format to use Rule:

ClearAll[myFunction]
myFunction /: MakeBoxes[myFunction[a_, b_, c_], TraditionalForm] :=
    TemplateBox[
        {ToBoxes[a], ToBoxes[b], ToBoxes[c]}, "myFunctionTag",
        DisplayFunction -> (SubsuperscriptBox[#1, #2, #3] &)
    ]

myFunction[h, 1, 2] // TeXForm

h_1^2

Note that I removed a superfluous HoldPattern in your definition.

Could you forward this issue somewhere? That is either is should accept RuleDelayed or the documentation of TemplateBox should stress that out. Currently the second example uses RuleDelayed for the DisplayFunction. — Kuba, Aug 09 '17 at 11:03
