Is there any faster implementation of DominantColors?

Question

The function DominantColors is a simple function but runs incredibly slow when the number n of dominant colors to find is large - it is currently the biggest bottleneck in my code:

tst = ExampleData[{"TestImage", "Lena"}];
gr = ListDensityPlot[SeedRandom[1]; RandomReal[{}, {4000, 3}],
  InterpolationOrder -> 0, Frame -> False, Mesh -> All,
  ImageSize -> 475]
polys = Cases[Normal@gr, _Polygon, \[Infinity]];
vpolys = Polygon[#[[1]], VertexTextureCoordinates -> #[[1]]] & /@
   polys;
pieces = Table[Graphics[{Texture[tst], p}], {p, vpolys}];
colors = Table[
   RandomChoice[DominantColors[p, 5][[2 ;;]]], {p, pieces}];
cpolys = Map[{#[[2]], Polygon[#[[1, 1]]]} &, Thread@{polys, colors}];
gcp = Graphics[cpolys]

Has anyone any ideas to reimplement it to be faster?

Motivation & Clarification

I use mathematica to do explorative art. I'm using this subroutine DominantColors as a tool in my various software art projects for example: I don't need someone to implement a specific image effect, rather I need a faster dominant-n-colors-finder. I'm thinking of using cudalink...

Answer 1

The function domCol below is about 100 times faster than DominantColors.

Basic plan: Create enough color bins throughout the color space occupied by the image; count the number of pixels in each bin; return the sorted colors. The function works in the LAB color space so we can use EuclideanDistance for the distance between colors. The centers of the bins are jiggled by a random offset each call, so that the return value is not deterministic. The option "RandomSeed" can be used to give a reproducible result.

Examples:

domCol[ExampleData[{"TestImage", "Mandrill"}], 20] // AbsoluteTiming

domCol[ExampleData[{"TestImage", "Lena"}], 20] // AbsoluteTiming

It seems to find similar colors to the ones found by DominantColors, although in a different order here and there.

Code:

Suppose DominantColors spends some time fiddling with constructing an optimal set of color bins, which seems a reasonable hypothesis. This approach does not, but uses a simple heuristic to get a binning that's likely to do a pretty good job. That seems the probable reason for the difference in performance. The function domCol uses a face-center cubic close-packing of spheres, with slightly larger spheres that overlap a little (radius 0.55 dx where dx is the diameter determined by the heuristic). Some of the space is not covered. (Technically, they're not really bins.) The distance can be set explicitly by the option MinColorDistance, which in this case will actually determine the exact color distance between adjacent bins, but the option exists already (for DominantColors). One could make the 0.55 fudge factor an option, too, for more control. With this approach Nearest is a convenient and efficient way to do the bin counts.

ClearAll[domCol];
Options[domCol] = {"RandomSeed" -> Automatic, MinColorDistance -> Automatic};
domCol[img_, n_, OptionsPattern[]] :=
 Module[{idata, nf, bounds, basis, points, colorbins, intensity},
  idata = Flatten[ImageData@ColorConvert[img, "LAB"], 1];
  nf = Nearest@idata;
  bounds = MinMax /@ Transpose@idata;
  With[{dx =
     OptionValue[MinColorDistance] /.
      Automatic -> (Times @@ Flatten[Differences /@ bounds]/n)^(1/3)/4},
   basis = LatticeData["FaceCenteredCubic", "Basis"];
   If[IntegerQ@OptionValue["RandomSeed"] ||
      StringQ@OptionValue["RandomSeed"],
    SeedRandom[OptionValue["RandomSeed"]]
    ];
   points = Tuples[Range[# - dx + RandomReal[{-dx, dx}/2], #2 + dx, dx] & @@@
      (Sort /@ (Inverse@Transpose[basis].bounds))].basis;
   colorbins = Select[points, Length@nf[#, {1, dx}] >= 1 &];
   intensity = Length@nf[#, {All, 0.55 dx}] & /@ colorbins
   ];
  LABColor /@ colorbins[[Ordering[intensity, -Min[n, Length@colorbins]]]] // Reverse
  ]

The use of the "FaceCenteredCubic" lattice is based in part on this answer by s0rce: Using LatticeData to fill a space with spheres in a face-centered cubic (fcc) lattice packing arrangement

Answer 2

Use of ColorQuantize Much faster. Not exactly the same, but close and for an art project is OK I think.

i = ExampleData[{"TestImage", "Lena"}];

QuaCol[i_, n_] := RGBColor /@ Union[Flatten[ImageData[ColorQuantize[i, n]], 1]]

Answer 3

The problem is not with DominantColors

Try varying the number of colours selected by running this snippet. I vary the number of selected colours from 1 to 10, and measure the time to calculate DominantColours ten times:

Table[
  First@AbsoluteTiming@
     Table[DominantColors[p, i], {p, RandomChoice[pieces, 10]}]
 , {i, 10}]

(* {6.544491, 7.658153, 6.025185, 7.401227, 6.483151,
    9.054305, 8.664255, 11.058545, 13.238622, 13.285135} *)

Empirically, the time increases linearly with the number of colours, but the constant overhead is very high --- basically the time your code requires has almost nothing to do with the number of colours selected.

The problem seems to be that each element of pieces is a complex image - it contains the whole Lena image for starters. Each element of pieces is 780 kB in size and - not knowing about how it works - it's unsurprising to me that it takes some time to compute.

If you try this with a bigger image than Lena you'll just run into more problems--- especially if you try to generate more than 4000 pieces because you're manipulating a bigger image. The solution is to not to fix DominantColors but to come up with a colour selection routine that isn't so memory intensive. If you rewrite the question with that in mind, I think a good answer could be found.
