َAdding the link of a web site

Question


    \documentclass[a4paper,10pt]{article}
    \usepackage[T1]{fontenc}

    \usepackage{geometry}
    \geometry{left=2cm,right=2cm,top=1.5cm,bottom=1.5cm}

    \usepackage{pifont}
    \usepackage{sectsty}

    \usepackage{graphicx}
    \usepackage{amsmath,amsfonts,amsthm}

    \usepackage[colorlinks=true,linkcolor=blue,urlcolor=blue]{hyperref}

    \frenchspacing
    \sectionfont{%
      \fontfamily{phv}\bfseries
      \sectionrule{0pt}{0pt}{-5pt}{1pt}%
    }
    \pagestyle{empty}

    \begin{document}

    %%%%%%%%%%%%%%%%%% Photo et title %%%%%%%%%%%%%%%%%%%%%%%%%

    \bigskip

    \begin{flushleft}

    \makebox[0pt][l]{%
      \fontfamily{phv}\large
      \begin{tabular}{@{}l@{}}
      \Huge\bfseries Name Name \\[1ex]
      Curriculum Vitae\\ (\today)
      \end{tabular}%
    }
    \hspace*{\fill}%
    \begin{tabular}{@{}c@{}}
      \includegraphics[width=0.15\textwidth]{example-image-9x16}
    \end{tabular}

    \end{flushleft}
\end{document}

I want to add a link to my ORCID account

like the following

Did you see the postings Is there a standard way to include ORCID in TeX / PDF? and IEEEtran - How to include ORCID in TeX/PDF with PdfLatex, and are you familiar with the package called orcidlink? — Mico, Dec 26 '21 at 06:09

score 2 · Accepted Answer · answered Dec 25 '21 at 19:37

2

Just like so? I'm using a tikz environment to create the circled text and by changing the hyperref parameters to make the link look white, you can also leave the hyperref parameters clean and modify the text in the tikz implementation of the circled node

\documentclass[a4paper,10pt]{article}
\usepackage[T1]{fontenc}
\usepackage{geometry}
\geometry{left=2cm,right=2cm,top=1.5cm,bottom=1.5cm}
\usepackage{pifont}
\usepackage{sectsty}
\usepackage{graphicx}
\usepackage{amsmath,amsfonts,amsthm}
\usepackage[colorlinks=true,linkcolor=white,urlcolor=white]{hyperref}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\usepackage{tikz}
\newcommand*\circled[1]{\tikz[baseline=(char.base)]{
            \node[shape=circle,draw,inner sep=2pt, fill=green, draw=green] (char) {\small #1};}}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\frenchspacing
\sectionfont{%
  \fontfamily{phv}\bfseries
  \sectionrule{0pt}{0pt}{-5pt}{1pt}%
}
\pagestyle{empty}
\begin{document}
%%%%%%%%%%%%%%%%%% Photo et title %%%%%%%%%%%%%%%%%%%%%%%%%
\bigskip
\begin{flushleft}
\makebox[0pt][l]{%
  \fontfamily{phv}\large
  \begin{tabular}{@{}l@{}}
  \Huge\bfseries Name Name $^{\text{\circled{\href{http://www.overleaf.com}{ID}}}}$ \[1ex]
  Curriculum Vitae\ (\today)
  \end{tabular}%
}
\hspace*{\fill}%
\begin{tabular}{@{}c@{}}
  \includegraphics[width=0.15\textwidth]{example-image-9x16}
\end{tabular}
\end{flushleft}
\end{document}

answered Dec 25 '21 at 19:37

Miguel Fernando Rangel Martnez

429
2
7

Thanks a lot. Just I hope that the color of the circle is like the pic – Student Dec 25 '21 at 19:43
what do you mean? – Miguel Fernando Rangel Martnez Dec 26 '21 at 02:37
@Student: The colour is RGB = (166, 206, 57) or Hex = #A6CE39. – Werner Dec 26 '21 at 06:39
@Werner What should I change in the answer? Thanks a lot – Student Dec 26 '21 at 09:54
@MiguelFernandoRangelMartnez I mean that I want to change the color as my pic. Thanks a lot – Student Dec 26 '21 at 10:10
Well, you can use the xcolor environment to generate a new color and use it in the fill and draw parameter in the tikz node. – Miguel Fernando Rangel Martnez Dec 26 '21 at 16:04
@MiguelFernandoRangelMartnez I hope that you edit your answer. Thanks a lot – Student Dec 26 '21 at 17:40
Could you please see my related question: https://tex.stackexchange.com/questions/628232/changing-a-color-of-a-link/628234?noredirect=1#comment1566894_628234 ? – Student Dec 29 '21 at 06:20
