environment subfigure undefined

Question

I want to place two images side by side and I have seen LaTeX figures side by side but one of the answers give me the Environment subfigure undefined error and I haven't the slightest idea why. The idea is to place two subfigures side-by-side within a main figure.

Here's my code:

\documentclass [10pt, a4paper]{article}
\usepackage[utf8]{inputenc}
\usepackage[portuguese]{babel}
\usepackage[T1]{fontenc}
\usepackage{hyphenat}
\usepackage{graphicx}
\usepackage{amsmath}
\usepackage{geometry}
\usepackage{subfig}
\begin{document}
\begin{figure}
\centering
\begin{subfigure}{0.5\textwidth}
  \centering
  \includegraphics[width=0.4\textwidth]{impedância Ri1.png}
  \caption{caption}
  \label{fig:sub1}
\end{subfigure} %
\begin{subfigure}{0.5\textwidth}
  \centering
  \includegraphics[width=0.4\textwidth]{impedância ri2.png}
  \caption{caption}
  \label{fig:sub2}
\end{subfigure}
\caption{caption}
\end{figure}
\end{document}

Any help?

Answer 1

You mix two different approaches together. You cannot use both of them at same time. I include both methods to achieve same result:

\usepackage{subcaption}

\documentclass [10pt, a4paper]{article}
\usepackage[hidelinks]{hyperref}
\usepackage[utf8]{inputenc}
\usepackage[portuguese]{babel}
\usepackage[T1]{fontenc}
\usepackage{hyphenat}
\usepackage{graphicx}
\usepackage{amsmath}
\usepackage{geometry}
\usepackage{subcaption}
\begin{document}
Left is \ref{fig:sub1}. Right is \ref{fig:sub2}
\begin{figure}
\centering
\begin{subfigure}{0.4\textwidth}
\includegraphics[width=\textwidth]{example-image}
\caption{caption}
\label{fig:sub1}
\end{subfigure}\hskip1ex
\begin{subfigure}{0.4\textwidth}
\includegraphics[width=\textwidth]{example-image}
\caption{caption}
\label{fig:sub2}
\end{subfigure}
\caption{caption}
\end{figure}
\end{document}

\usepackage{subfig}

\documentclass [10pt, a4paper]{article}
\usepackage[hidelinks]{hyperref}
\usepackage[utf8]{inputenc}
\usepackage[portuguese]{babel}
\usepackage[T1]{fontenc}
\usepackage{hyphenat}
\usepackage{graphicx}
\usepackage{amsmath}
\usepackage{geometry}
\usepackage{subfig}
\begin{document}
Left is \ref{fig:sub1}. Right is \ref{fig:sub2}.
\begin{figure}
\centering
\subfloat[caption]{\includegraphics[width=0.4\textwidth]{example-image}\label{fig:sub1}}\hskip1ex
\subfloat[caption]{\includegraphics[width=0.4\textwidth]{example-image}\label{fig:sub2}}
\caption{caption}
\end{figure}
\end{document}

output:
