I'm trying to do some automatically generated LaTeX documents and I'm wondering how can I split subfigures (with captions a, b, c, etc.) over many pages automatically. This is my code and the only thing which I would like to improve is to show figure caption (here Title) but only for the last row on each page, not after each row. How can I do that?

\documentclass[11pt]{article}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc} % ensure your document is UTF-8
\usepackage[spanish]{babel}

\usepackage[demo]{graphicx} % demo option just for testing
\usepackage{caption}
\usepackage{subcaption}
\usepackage{float}
\usepackage[showframe]{geometry}
\usepackage{float}


\begin{document}


\centering
\begin{figure}[htb]
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 1.}
    \label{fig:1}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 2.}
    \label{fig:2}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 3.}
    \label{fig:1}
\end{subfigure}
\caption{Title}
\end{figure}


\begin{figure}[H]\ContinuedFloat
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 1.}
    \label{fig:1}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 2.}
    \label{fig:2}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 3.}
    \label{fig:1}
\end{subfigure}
\caption{Title}
\end{figure}


\begin{figure}[H]\ContinuedFloat
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 1.}
    \label{fig:1}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 2.}
    \label{fig:2}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 3.}
    \label{fig:1}
\end{subfigure}
\caption{Title}
\end{figure}


\begin{figure}[H]\ContinuedFloat
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 1.}
    \label{fig:1}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 2.}
    \label{fig:2}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 3.}
    \label{fig:1}
\end{subfigure}
\caption{Title}
\end{figure}


\end{document}
Display Name
  • 46,933
Math122
  • 241
  • See https://tex.stackexchange.com/questions/529505/text-comes-in-between-figures-while-using-continuedfloat and https://tex.stackexchange.com/questions/520427/allow-figure-to-continue-next-page-if-it-doesnt-fit – John Kormylo May 28 '22 at 16:32
  • It doesn't solve my problem, I want to add caption for each figure – Math122 May 28 '22 at 17:10
  • Please note that several graphics have the same label. This will cause problems if you want to use \ref{fig:1} for example. – Unknown May 29 '22 at 00:00

2 Answers2

0

I'm not sure if it helps You and it is not automatically at all but better than Your variant:

\documentclass[11pt]{article}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc} % ensure your document is UTF-8
\usepackage[spanish]{babel}

\usepackage[demo]{graphicx} % demo option just for testing
\usepackage{caption}
\usepackage{subcaption}
\usepackage{float}
\usepackage[showframe]{geometry}
\usepackage{float}
\newcommand{\treeimg}[7]{%
\begin{figure}[htb]
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/#1}
    \caption{#2}
    \label{fig:1}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/#3}
    \caption{#4}
    \label{fig:2}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/#5}
    \caption{#6}
    \label{fig:1}
\end{subfigure}
\caption{#7}
\end{figure}}


\begin{document}
\treeimg{1.jpg}{captionof1.jpg}{1.jpg}{captionof2.jpg}{1.jpg}{captionof3.jpg}{caption}
\treeimg{1.jpg}{captionof1.jpg}{1.jpg}{captionof2.jpg}{1.jpg}{captionof3.jpg}{caption}
\treeimg{1.jpg}{captionof1.jpg}{1.jpg}{captionof2.jpg}{1.jpg}{captionof3.jpg}{caption}
\treeimg{1.jpg}{captionof1.jpg}{1.jpg}{captionof2.jpg}{1.jpg}{captionof3.jpg}{caption}
\end{document}

enter image description here

WinnieNotThePooh
  • 3,008
  • 1
  • 7
  • 14
0

Your best bet is to make the first float [bp] and the rest [tbp!]. This will fill up to \bottomfraction of the first page and possibly all of the second page.

\documentclass[11pt]{article}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc} % ensure your document is UTF-8
\usepackage[spanish]{babel}

\usepackage[demo]{graphicx} % demo option just for testing
\usepackage{caption}
\usepackage{subcaption}
\usepackage[showframe]{geometry}
%\usepackage{float}% friends don't let frineds use [H]


\let\bottomfraction=\topfraction
\let\floatpagefraction=\topfraction


\usepackage{lipsum}


\begin{document}


\begin{figure}[bp]
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 1.}
    \label{fig:1}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 2.}
    \label{fig:2}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 3.}
    \label{fig:1}
\end{subfigure}
\caption{Title}
\end{figure}


\begin{figure}[tbp!]\ContinuedFloat
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 1.}
    \label{fig:4}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 2.}
    \label{fig:5}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 3.}
    \label{fig:6}
\end{subfigure}
\caption{Title}
\end{figure}


\begin{figure}[tbp!]\ContinuedFloat
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 1.}
    \label{fig:7}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 2.}
    \label{fig:8}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 3.}
    \label{fig:9}
\end{subfigure}
\caption{Title}
\end{figure}


\begin{figure}[tp!]\ContinuedFloat
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 1.}
    \label{fig:10}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 2.}
    \label{fig:11}
\end{subfigure}
    \hfill
\begin{subfigure}[t]{.32\textwidth}
    \includegraphics[width=\textwidth]{images/1.png}
    \caption{Image 3.}
    \label{fig:12}
\end{subfigure}
\caption{Title}
\end{figure}


\lipsum[1-6]


\end{document}
