When I add images using the following code

    \begin{figure}
        \centering
        \includegraphics[width=0.7\linewidth]{images/CACPSP}
        \caption{Conductivity of SDS at fixed concentration of NaCl and PEO}
        \label{fig:cacpsp}
    \end{figure}

I am getting the following output enter image description here The image is present in my images/ folder and I don't know what to do now. I have tried compiling it using texstudio and overleaf but am still getting the same issue

Matthew Shoults
  • 1
  • 1
    This means you probably have \usepackage[draft]{graphicx} in your preamble. Remove the [draft] part and the image will show. Or indeed as @Zarko commented the option can be given to the documentclass, which then propagates it to all packages that have this option (such as graphicx). – Marijn Dec 19 '22 at 13:53
  • Welcome to TeX.SE! Please extend your code fragment to completes small document with your figure, which we can test as it is. It seems that you havedraft option for \documentclass. – Zarko Dec 19 '22 at 13:53
  • Note that in addition to draft given as option to graphicx it can also have been given as an option to the class your are using (of which you provide no information) – daleif Dec 19 '22 at 13:55
