I am creating document for IEEE conference

\documentclass[conference]{IEEEtran}
\IEEEoverridecommandlockouts

Goal: Create side by side image, that doesn't affect other table caption and bibliography indexing

What I've tried:

  1. Using subcaption But it messed up the caption on other table and other figures
\usepackage{graphicx}
\usepackage[utf8]{inputenc}
\usepackage[pdftex]{graphicx}
\usepackage{stfloats}
\usepackage{flushend}
\usepackage{cite}
\usepackage{subcaption}
  1. Using subfig But for some reason the bib index order is messed up
\usepackage{graphicx}
\usepackage[utf8]{inputenc}
\usepackage[pdftex]{graphicx}
\usepackage{stfloats}
\usepackage{cite}
\usepackage{flushend}
\ifCLASSOPTIONcompsoc
    \usepackage[caption=false, font=normalsize, labelfont=sf, textfont=sf]{subfig}
\else
\usepackage[caption=false, font=footnotesize]{subfig}
\fi

enter image description here

Question:

  1. So what package is best to keep IEEE format when creating side by side image?
  2. What I read so far subfig is the best option, but if that's the case, what went wrong with my second try?
ordem
  • 1
  • You are using several packages I would avoid with IEEE, such as flushend, cite, stfloats and subcaption. IIRC, IEEE already provides most of the features. – John Kormylo Apr 17 '21 at 00:57
  • Thanks for the suggestion, I did quick check and yes removing stfloats did fix the problem, but the reason I used stffloats is I have table that spans two-column that I want to show at the bottom page, and I read that two-column format doesn't have 'bottom' – ordem Apr 17 '21 at 02:33
  • According to section X of the IEEEtran manual, bottom floats are strongly discouraged, but are possible using dblfloatfix. It may conflict with other packages, and the order in which they are loaded may make a difference. – John Kormylo Apr 17 '21 at 15:03
